LAVA BASIC DM RAL Infrared Heater

The LAVA BASIC-DM is an infrared heater only 22 mm deep, which is suitable for both ceiling and wall heating and generates infrared radiant heat using a special magnetic field-free heating element.

Unlike conventional heaters, it not only heats the air, but also all people and objects in the room. The appliances are also ideal for full or zone heating.

When installed in false ceilings, the heating is fully integrated into the ceiling. Ceiling installation allows the room to be optimally utilized and also prevents damage to the heater.

Available in the colors traffic white RAL 9016, nano anthracite RAL 7016 and in the LAVA BASIC-DM RAL version in all RAL colors and in up to 6 outputs (350-1500 W).

Technical Information

• Finely textured surface

• Body: steel housing

• Protection rating: IP 21

• Surface temperature: ceiling mounting max. 120 °C / wall mounting max. 95 °C

• Mounting depth: 52 mm

• Test mark: TÜV, CE compliant

• Connection cable: 1 m, 3 x 1.5 mm² without plug

• Without Plug & Play connection

• Power: 230 V.
