LAVA BASIC 3.0 Infrared Heating Panel for Walls & Ceilings (EIHA Certified)

From £316.67 (EX VAT)

Price:

  • Energy Efficient
  • Reduce Heating Cost
  • Easy Installation
  • Zero Maintenance
  • Fast Delivery
  • 10 Year Warranty
  • EIHA Certified
Colour
White (RAL 9016) or Nano-anthracite (RAL 7016)
Temperature
Max. 95 °C wall / 120 °C ceiling installation
Voltage
230 V
Output
200 - 1350 W
Surface temperature
Ceiling installation max. 120 °C / wall installation max. 95 °C
Material
Steel sheet
Ceiling installation heights
min. 1.85 m up to max. 2.8 m (optimal 2.40 - 2.60 m
Device/installation depth
18/48 mm
IP Rating
IP X4
IEC Protection Class
I
Connection cable
1 m; 3 x 1.0 mm² (hard wiring required - not supplied with a UK plug)
Certification
EIHA quality label, TÜV NORD
Warranty
up to 10 years with free ETHERMA eWARRANTY registration (within 6 months of purchase)

Product description

Discover the LAVA BASIC 3.0, ETHERMA's most advanced steel infrared heating panel and one of the first in Europe to carry the EIHA quality label. With a slimline panel just 18 mm thick and a specially developed coating, it combines stylish, minimalist design with exceptional heat output - for walls, ceilings and modular ceiling grids alike.

That EIHA badge is worth pausing on. The EIHA Quality Label, created by the European Infrared Heating Alliance and certified through independent testing institutes such as TÜV, is only awarded to panels that prove a radiation efficiency of at least 40%, tested CE certification, Ecodesign compliance and ongoing annual production checks. In a market full of unverified claims, it is independent confirmation that this panel performs exactly as promised.

The innovative coating ensures an optimal radiant effect, so heat is distributed evenly and efficiently through the room rather than wasted. You feel warm sooner, use less energy and cut your heating costs - and the high-quality materials, certified by TÜV NORD, promise an exceptionally long, maintenance-free lifespan.

The LAVA BASIC 3.0 stands for flexibility. Use it as zone heating for targeted areas or as full heating for an entire room; install it on the wall, on the ceiling (from 1.85 m up to 2.8 m) or drop the 325 W and 680 W sizes into a modular ceiling. Installation is so simple it can be done by one person, and the panel is hard wired by a qualified electrician (please note it is not supplied with a UK plug).

Eight outputs from 200 W to 1350 W are available in white (RAL 9016), with the four most popular sizes (325, 450, 680 and 900 W) also available in nano-anthracite (RAL 7016). Choose the panel-only version and pair it with your preferred ETHERMA thermostat (Ecodesign-ready - see accessories), or upgrade to the SMART variant with SMARTBOX and SMARTCUBE for full WiFi control via the ETHERMA SMART app, fully Ecodesign-compliant out of the box.

Backed by an ETHERMA warranty of up to 10 years - just register your free ETHERMA eWARRANTY within 6 months of purchase. Select your finish, output and control option above and order today from ARC Thermal Solutions - the exclusive UK partner for ETHERMA.

Colours

Nano-anthracite White

This installation video shows you how to install the LAVA BASIC 3.0 infrared heating panel quickly and easily. Follow our step-by-step instructions to install the heating panel safely and efficiently on the wall or ceiling.

LAVA BASIC 3.0 infrared heating panel installation

Want This Installed - or Not Sure If It's Right for You?

You can order this product directly, but if you'd prefer professional installation or want to confirm it's the right solution for your space, our team is happy to help. Get in touch for expert advice and a no-obligation installation quote.
